Pipe Extrusion Line Pe Hot Plastic Extrusion Welding Gun Plastic Fabrication

Short Description:

1. Name: Plastic Extruder Welder

2. Model: R-SB20, R-SB30, R-SB40, R-SB50


Product Detail

Product Tags

Detail Information

Voltage: 230V Welding Area: 8-30mm
Weight: 16kg Usage: Plastic Fabrication
Model: R-SB20 R-SB30 R-SB40 R-SB50 Material: HDPE/PP/PVDF

Product Description

Pipe Extrusion Line Pe Hot Plastic Extrusion Welding Gun Plastic Fabrication
Fabrication–STARGUN
 STARGUN is the line of handy and easy to use extruder welders.All models distinguish for being light ,compact and very smooth during the welding phase.The entire line is supported by a series of interchangeable Teflon shoes which allow the STARGUN to adapt to every kind of welding situation:from plane sheets to oblique angles.Thanks to their versatility they are able to weld different types of fabrications like:containing tanks,fume treatment towers,scrubbers,chemical hoods,aspiration systems and for joining linings and geo-textiles. All the models can be provided with different types of handle which allow to customize the extruder in order to give the operator a high-performance instrument.In the chart below find the main characteristics tha make of the STARGUN a unique instrument.

-Backlight display

-Welding-area spot light LEDs

-Output redulator(for back handle and pistol grip)

-Temperature control safety system cold start control

-Built -in blower

-Double T ° controller blower/extrusion chamber

-Rotating side-handle

-Replaceable 360 ° rotating teflon shoe

Supplied with:Aluminium case,extruder support,rod guide 4-5 mm, 90° teflon shoe,teflon block and teflon flat shoe

Specification

20191119154844_48681
Type R-SB 20 R-SB 30 R-SB 40
Materials
HDPE/PP/PVDF HDPE/PP/PVDF
HDPE/PP/PVDF
Rod
3-4mm 3-4-5mm
4-5 mm
Output:up to
2/Kg/h 3.2Kg/h
4Kg/h
Dimensions
450*310*100mm 500*280*100mm
640*200*100mm
Weight
6.9Kg 7Kg
7.5Kg
Voltage
230V 230V
230V
Absorption
3100W 3350W
3330 W
Frequency
50/60 Hz 50/60 Hz 50/60 Hz
Sheets
4-20mm 4-30mm
8-30mm

Packing

Packing in one aluminiun case:Dimensions:82*26*40cmN.W:15.5kgG.W:16kg

20191111154615_73725

Application

Customized plastic fabrication using.

20191119154904_76278
