Ductile Cast Iron Universal Flange Adapotor/Coupling Fitting

Short Description:

1. Connection for pipes in material ductile iron, steel , HDPE , PVC etc.

2. Working pressure PN10/PN16

3. Maximum temperature -10°C to 70°C

4. Suitable for portable water, neutral liquids and sewage

5. Wide tolerance range

Send email to us Send email

Product Detail

Specification

Application

Product Tags

CHUANGRONG is a share industry and trade integrated company, established in 2005 which focused on the production of HDPE Pipes, Fittings & Valves, PPR Pipes, Fittings & Valves, PP compression fittings & Valves, and sale of Plastic Pipe Welding machines, Pipe Tools, Pipe Repair Clamp and so on.

Ductile Cast Iron Universal Flange Adapotor/Coupling Fitting

Detail Information

No.	Name	Material	Specification
1	Body	Ductile Iron	GGG50
2	End Ring	Ductile Iron	GGG50
3	Gasket	Rubber	EPDM or NBR
4	Bolt	Galvanized Steel	ISO898-1:1999
5	Washer	Galvanized Steel
6	Nut	Galvanized Steel	ISO898-2:1992
7	Cap	Plastic

Product Description

Universal Flanged Adaptor or Universal Coupling are designed for pipelines , As a wide tolerance system.It will fit most standard pipe materials and therefore dramatically reducesthe number of dedicated Flanged Adaptors which need to be stocked for maintenance purposes.When connecting PE pipes , It is important that pipe inserts are fitted to the PE pipes .

It can fit most standard pipe materials and therefore dramatically reduces the stocks of dedicated couplings.
It is suitable for steel , GRP, PVC, PE, Ductile Iron , Cast Iron and Asbestors Cement pipes.

Size from DN40-DN1200

PRESSURE
PN10, PN16, Flange according to ISO2531/ EN545,/EN1092

MATERIAL

Body	Ductile Iron GGG50
Gland	Ductile Iron GGG50
Gasket	EPDM according to EN681-1
Bolt &Nut	Galvanized carbon steel / hot dip galvanized steel/dacromet coating steel 8.8 grade
Coating	Fusion boned epoxy more than 250 micron/ Rilsan Nylon

CHUANGRONG has an excellent staff team with rich experience. Its principal is Integrity, Professional and Efficient. It has established business relationship with more than 80 countries and zones in relative industry. Such as United States, Chile, Guyana, The United Arab Emirates, Saudi Arabia, Indonesia, Malaysia,Bangladesh, Mongolia, Russia, Africa and so on.

If you have any questions, you can feel free to contact us in anytime .

Welcome to contact us for products details and professional service.

Please send email to: chuangrong@cdchuangrong.com or Tel: + 86-28-84319855

Previous: DI Ductile Cast Iron Quick Release Flanges Adaptor for HDPE Pipe

Next: Ductile Iron Theaded Tapping Saddle with Stainless Steel Band Strapped for DI/Steel Pipe

DN	RANGE(MM)	L(MM)	D(MM)	BOLT
DN	RANGE(MM)	L(MM)	D(MM)	SIZE	QTY
50	59-72	75	165	M12*130	2
65	72-85	75	185	M12*130	2
80	88-103	76	185	M12*130	4
100	93-117	78	218	M12*130	4
125	125-140	78	250	M12*130	4
150	155-175	80	272	M12*130	4
200	218-235	85	335	M12*130	4
225	235-252	85	355	M12*130	4
250	265-280	90	405	M12*130	6
300	315-332	90	460	M12*130	6
350	351-368	110	510	M16*180	8
400	400-429	110	580	M16*180	8
450	455-472	115	640	M16*180	10
500	500-532	120	690	M16*180	10
600	600-630	130	820	M16*180	10
